Metal elevator control system keypad stainless steel B733
It is made of stainless steel.Vandal resistance. The button surface and pattern can be customized according to customer requirements. It is mainly for access control system, industrial telephone, vending machine, security system and some other public facilities.
1.9 Keys vandal-proof IP65 stainless steel matrix keypad. 9 function keys.
2.Keys are good touch feeling and accurate data input without any noise.
3.Easy to install and maintenance; flush mount.
4.Our panel and buttons are made of stainless steel 304, which is highly rugged, vandal-proof, against corrosion, weather-proof.
5.Fonts and pattern of key surface can be customized.
6.The keypad is waterproof, anti-drilling and removal-proof.
7.The keypad uses double-sided PCB and mental dome; Good contact.
8 . Suitable for the device which needs to select ↑↓←→.
9.The labels on the buttons are made by etching, and fill in high strength paint.
Keypad application: security system and some other public facilities.
|
Item |
Technical data |
|
Input Voltage |
3.3V/5V |
|
Waterproof Grade |
IP65 |
|
Actuation Force |
250g/2.45N(Pressure point) |
|
Rubber Life |
More than 500 thousand cycles |
|
Key Travel Distance |
0.45mm |
|
Working Temperature |
-25℃～+65℃ |
|
Storage Temperature |
-40℃～+85℃ |
|
Relative Humidity |
30%-95% |
|
Atmospheric Pressure |
60Kpa-106Kpa |
Any appointed connector could be made as customer's request. Let us know the exact item No. in advance.
85% spare parts are produced by our own factory and with matched test machines, we could confirm the function and standard directly.
