Industrial VOIP Intercom Phone for Construction Communications-JWAT943
Short Description:
It is an industrial weatherproof phone with a solid case made of cold rolled steel with a powder coated finish for high mechanical strength and impact resistance, a highly reliable product with a long MTBF.
Weatherproof Intercom Phone is designed for voice communication in harsh & hostile environment where reliability efficiency and safety are of prime importance. Like Transportation Communications in tunnel, marine, railway ,highway, underground, power plant, dock,etc.
The body of the telephone it is made of Cold rolled steel, a very strong material, can be powder coated with different colors,used with generous thicknesses. The degree of protection is IP67.
Several versions are available, with stainless steel armored cord or spiral, with keypad, without keypad and on request with additional function buttons. Also we have the model with camera if needed.
1. Standard SIP 2.0 telephone.
2. Robust housing, Aluminum alloy die-casting body.
3. Rolled steel face-plate with epoxy powder coated providing complete protection against dust and moisture.
4. Vandal resistant stainless buttons.
5. All weather protection IP66-67.
6. One button for speed dial.
7. Support G.711 A/U, G.722 8000/16000, G.723, G.729.
8. WAN/LAN: support Bridge mode.
9. Support DHCP get IP on WAN port.
10. Support PPPoE for xDSL.
11. Support DHCP get IP on WAN port.
12. Temperature: Operating: -30°C to +65°C Storing: -40°C to +75°C.
13. With external power supply, sound level is more than 80db.
14. Hands-free Operation.
15. Wall mounted.
16. Self-made telephone spare part available.
17. CE, FCC, RoHS, ISO9001 compliant.
This Weatherproof Intercom Phone Is Very Popular For Construction Communications,Tunnels, Mining, Marine, Underground, Metro Stations, Railway Platform, Highway Side, Parking Lots, Steel Plants, Chemical Plants, Power Plants And Related Heavy Duty Industrial Application, Etc.
| Item | Technical data |
| Power Supply | POE or 12VDC |
| Standby Work Current | ≤1mA |
| Frequency Response | 250～3000 Hz |
| Ringer Volume | >85dB(A) |
| Corrosion Grade | WF2 |
| Ambient Temperature | -40～+70℃ |
| Atmospheric Pressure | 80～110KPa |
| Relative Humidity | ≤95% |
| Anti-vandalism Level | IK09 |
| Installation | Wall-mounted |
| Power Supply | POE or 12VDC |
If you have any color request, let us know the Pantone color No.
85% spare parts are produced by our own factory and with matched test machines, we could confirm the function and standard directly.
