LED backlight rugged metal keypad for fuel dispenser B802

Short Description:

It’s 4×5 20 keys vandal proof IP65 stainless steel keypad, matrix design with carbon-on-gold key switch technology. LED color available for customer’s choice. Specially designed keyboards meet the high demands with ragrd to design, functionality, longevity and high protection level. Mainy used for fuel dispenser and other public facilities.

With a professional R&D team in industrial telecommunication filed for 17 years, we could customize handsets, keypads, housings and telephones for different applications.

Send email to us

Product Detail

Product Tags

Product Introduction

High quality stainless steel made, LCD display design. Mainly for fuel dispenser, industrial telephone, vending machine, security system and some other public facilities.

Features

1. Material: 304# brushed stainless steel.
2. LED color is customized.
3. 1.5mm thickness UL approved printed circuit board with golden fingers
4.Buttons layout could be customized as clients’ request.
5.Keys layout can be customized.

Application

The keypad will be used in fuel dispenser.

Parameters

Item	Technical data
Input Voltage	3.3V/5V
Waterproof Grade	IP65
Actuation Force	250g/2.45N(Pressure point)
Rubber Life	More than 1 million cycles
Key Travel Distance	0.45mm
Working Temperature	-25℃～+65℃
Storage Temperature	-40℃～+85℃
Relative Humidity	30%-95%
Atmospheric Pressure	60Kpa-106Kpa
LED color	Customized
