12 keys digital Stainless steel keypad for strongbox B706
The keypad mainly used for strongbox and other customize product.Specially designed keyboards meet the highest demands with regard to design, functionality, longevity and high protection level.
1.Keypad made of stainless steel. It is Vandal resistance.
2.Font button surface and pattern can be customized according to customer requirements.
3.Buttons layout could be customized as clients' request.
4.Keypad connector could be customized.
The keypad mainly used in vending machines.
|
Item |
Technical data |
|
Input Voltage |
3.3V/5V |
|
Waterproof Grade |
IP65 |
|
Actuation Force |
250g/2.45N(Pressure point) |
|
Rubber Life |
More than 500 thousand cycles |
|
Key Travel Distance |
0.45mm |
|
Working Temperature |
-25℃～+65℃ |
|
Storage Temperature |
-40℃～+85℃ |
|
Relative Humidity |
30%-95% |
|
Atmospheric Pressure |
60Kpa-106Kpa |
Any appointed connector could be made as customer's request. Let us know the exact item No. in advance.
85% spare parts are produced by our own factory and with matched test machines, we could confirm the function and standard directly.
