Stainless steel keypad for public storage cabinet B761

Short Description:

It’s 20 buttons keypad which is mainly used for public storage cabinet, high quality stainless steel made provides the function of vandal resistance and dust proof. Keys layout can be custom made which meets different public facilities.

With a professional R&D team in industrial telecommunication filed for 17 years, we could customize handsets, keypads, housings and telephones for different applications.

Send email to us

Product Detail

Product Tags

Product Introduction

The keypad mainly used for vending machine and other customize product.

Features

1.Keypad made of stainless steel.Vandal resistance.
2.Font button surface and pattern can be customized according to customer requirements
3.waterproof, vandalproof, explosionproof.
4.keys layout can be customized.

Application

Keypad mainly used in vanding machine or other customize products.

Parameters

Item	Technical data
Input Voltage	3.3V/5V
Waterproof Grade	IP65
Actuation Force	250g/2.45N(Pressure point)
Rubber Life	More than 500 thousand cycles
Key Travel Distance	0.45mm
Working Temperature	-25℃～+65℃
Storage Temperature	-40℃～+85℃
Relative Humidity	30%-95%
Atmospheric Pressure	60Kpa-106Kpa
