Visualization Paging Console Phone JWA020
JWA020 is a visualization paging console phone for industry customer. It is equipped with a goose neck microphone and supports HD hands-free calling. With intelligent programmable DSS buttons, you can set up a one-click call function to improve communication efficiency. It is compatible with the standard SIP protocol and can be used as a monitoring center or host for office manager with functions such as make calls for external & internal phones, two-way intercom, monitoring, and broadcasting. The JWA020 improves the management efficiency and emergency response capabilities.
1. 20 SIP lines, 3-way conference, hotspot
2. HD audio on speakerphone and handset
3. Movable type Directional External Gooseneck Microphone
4. 4.3”main color display, 2x3.5”side color displays for DSS keys
5. Built-in Bluetooth
6. Wi-Fi connectivity(Via Wi-Fi dongle)
7. Up to 106 DSS keys(42 tri-colored physical keys)
8. Video Codec H.264 support for receiving video calls
9. Dual Gigabit ports, integrated PoE
10. Stand with 2 adjustable angles of 40 and 50 degrees
11. Compatible with major platforms: Asterisk, Broadsoft, 3CX, Metaswitch, Elastix, Avaya etc.
1. Local Phonebook (2000 entries)
2. Remote Phonebook (XML/LDAP, 2000 entries)
3. Call logs (In/out/missed, 1000 entries)
4. Black/White List Call Filtering
5. Screen saver
6. Voice Message Waiting Indication (VMWI)
7. Programmable DSS/Soft keys
8. Network Time Synchronization
9. Built-in Bluetooth 2.1: Support Bluetooth headset
10. Support Wi-Fi Dongle
11. Support Plantronics wireless headset (Through Plantronics APD-80 EHS Cable)
12. Support Jabra wireless headset (Through Fanvil EHS20 EHS Cable)
13. Support Recording (Through Flash Drive or Server Recording )
14. Action URL / Active URI
15. uaCSTA
| Call Features | Audio |
| Call out / Answer / Reject | HD Voice Microphone/Speaker (Handset/Hands-free, 0 ~ 7KHz Frequency Response) |
| Mute / Unmute (Microphone) | HAC handset |
| Call Hold / Resume | Wideband ADC/DAC 16KHz Sampling |
| Call Waiting | Narrowband Codec: G.711a/u, G.723.1, G.726-32K, G.729AB, AMR, iLBC |
| Intercom | Wideband Codec: G.722, AMR-WB, Opus |
| Caller ID Display | Full-duplex Acoustic Echo Canceller (AEC) |
| Speed Dial | Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) /Background Noise Estimation (BNE) / Noise Reduction (NR) |
| Anonymous Call (Hide Caller ID) | Packet Loss Concealment (PLC) |
| Call Forwarding (Always/Busy/No Answer) | Dynamic Adaptive Jitter Buffer up to 300ms |
| Call Transfer (Attended/Unattended) | DTMF: In-band, Out-of-Band – DTMF-Relay(RFC2833) / SIP INFO |
| Call Parking/Pick-up (Depending on server) | |
| Redial | |
| Do-Not-Disturb | |
| Auto-Answering | |
| Voice Message (On server) | |
| 3-way Conference | |
| Hot Line | |
| Hot desking |
