Outdoor Waterproof Telephone With LCD Display-JWAT305P-X
Short Description:
The JWAT305P-X is a rugged communication terminal designed for extremely harsh industrial environments. Completely sealed within a corrosion-resistant die-cast aluminum alloy waterproof housing, it offers superior protection. Whether in a dusty production workshop or a high-humidity outdoor dock, the JWAT305P-X ensures uninterrupted critical communications.
The JWAT305P-X is a high-performance industrial communication terminal engineered for the most demanding environments. Specifically designed for tunnels and subways, this outdoor telephone undergoes rigorous salt spray testing (ranging from 4 days to 4 weeks) to ensure long-term durability and corrosion resistance in maritime and industrial settings.
This weatherproof Industrial Phone with Display Screens is very popular for Tunnels, Mining, Marine, Underground, Metro stations, Railway platforms, highways side, Hotels, Parking lots, Steel Plants, Chemical plants, Power plants, and related heavy duty industrial applications, etc.
1. Aluminum alloy die-casting shell, high mechanical strength and strong impact resistance.
2. Heavy Duty handset with hearing Aid compatible receiver, Noise canceling microphone.
3. Vandal resistant zinc alloy keypad.
4. HD sound.Armored stainless steel handset cable or curly cord handset optional.
5. Indicator light when have incoming call optional.
6. LCD display, it can show talking time, dialing number, date, own number, and caller number.
7. Support SIP 2.0（RFC3261）,RFC Protocol.
8. Full keyboard with redial /mute/speed dial/hang up function.(optional)
9. Ringer Volume: about 85-90 db at 1m.
10. Weather proof Protection class to IP66-IP67.
11. The available colors as an option.
12. Wall mounted, Simple installation.
13. Self-made telephone spare part available.
14. CE, FCC, RoHS, ISO9001 compliant.
Joiwo creates offshore platform communications for your operational crew to stay connected during their everyday operations, especially in hazardous areas. You get integrated solutions to provide crew safety and increase operational efficiency. We create reliable solutions to ensure all your crew members receive critical messages in time and all alarm systems are distributed properly.
| Protocol | SIP2.0(RFC-3261) |
| Speaker | Power 10W |
| Volume Control | Adjustable |
| Operating humidity | 0% to 90% |
| Temperature range | -30°C to +65°C |
| Power Supply | 12V (±15%) / 1A DC or PoE |
| LAN | 10/100BASE-TX s Auto-MDIX, RJ-45 |
| WAN | 10/100BASE-TX s Auto-MDIX, RJ-45 |
| Number of lines | 2 SIP Lines |
| Wan modes | Static IP/ Dynamic IP/ PPPOE |
| Net | VLAN support
Suppors Bridge mode for Wan /Lan ports Static IP Dynamic routing |
| SIP | SIP register/SIP domain
SIP authentication (nonce, base, MD5) DNS-name server |
| Codes | G.729、G.723、G.711、G.722、G.726,etc. |
| DTMF | SIP info
DTMF relay RFC2833 |
| Sound | Full-duplex communication with echo cancellation (G.168)
VAD (voice activity detection) CNG (comfort noise generator) AEC (echo cancellation) |
| Management | Web interface
Telnet SSH Auto-provisioning of configuration files SNMP TR-069 |
| Weight | 6 KG |
| Installation | Wall-mounted |
Our industrial telephones are protected by a weather-resistant metallic powder coating—a resin-based material that is electrostatically sprayed and heat-cured to form a dense, uniform layer on metal surfaces. Unlike liquid paint, it provides superior durability and environmental protection without VOCs.
Key advantages:
Weather Resistance: Resists UV, rain, and corrosion.
Durable & Scratch-Resistant: Stands up to impact and daily wear.
Eco-Friendly: Contains no volatile organic compounds.
- Our telephone undergoes a multi-step testing process to ensure exceptional quality and reliability. Our tests include structural, performance, and functional assessments, designed to simulate real-world conditions and exceed industry standards. Key methods such as keystroke lifespan testing, salt spray testing, and waterproof testing are applied to guarantee durability. Our professional waterproof phones achieve an IP66-IP67 rating. An IP67 rating means the device is completely dustproof and can withstand being submerged in up to 1 meter of water for 30 minutes without damage. These tests ensure that the product remains functional in harsh environments, providing customers with a device they can trust for long-term use. Testing is not just a step in our production process; it’s a commitment to excellence.
85% spare parts are produced by our own factory and with matched test machines, we could confirm the function and standard directly.
